Maps and scale drawings

​​In a nutshell

Many maps and drawings come equipped with a scale, so that you can measure the drawing and use the scale to compute the true distances on the map or dimensions of the drawing. This lesson covers how to read and use scales on maps, or drawings in general.



Reading maps

Most maps are drawn so that north is up. Whenever this is not the case, you should expect the map to feature a compass point indicating the direction of north.


A map must have a scale. You can measure the distance between two points on the map with a ruler, then use the scale to work out what the distance between the corresponding two points in the real world is, via the following procedure:


PROCEDURE

1.
Measure the length of the given scale with a ruler.
2.
Measure the distance between the two points on the map you wish to compute the real distance between with a ruler.
3.
DIvide the distance you measured in step 222. by the length of the scale.​
4.
Multiply the number computed in step 333. by the length written on the scale.​


Example 1

On the following map, what is the real distance between the points AAA​ and BBB?

Maths; Angles and geometry; KS4 Year 10; Maps and scale drawings


Use your ruler to measure the length of one of the boxes. The scale given in the bottom right is one box length long.


Measure the distance between AAA​ and BBB on your screen with a ruler, and divide it by the length of one of the boxes on your screen (which you just measured), to get that the distance corresponds to 555 box lengths​.

(Alternatively, you could notice that the point BBB is 333 box lengths to the right, and 444 box lengths up, from AAA.  Using Pythagoras' theorem, the distance between AAA and BBB on the map is 32+42=5\sqrt{3^2 + 4^2} = 532+42​=5 box lengths.)


Using the scale, compute that the real distance between the points AAA and BBB must be:


5×10m=50m5 \times 10m = 50m5×10m=50m​​


Therefore, the real distance between the points AAA and BBB is 50m‾\underline{50m}50m​.


​

Scales as a ratio

Scales can be given as a ratio. Suppose in example 111, you measured one box length to be 1cm1cm1cm. There are 10×100=100010 \times 100 = 100010×100=1000​ centimetres in 10m10m10m. So, any distance you measured on the map with your ruler would need to be multiplied by 100010001000 to give you the corresponding distance in the real world. This is a scale of 1:10001:10001:1000​.


In general, the most simplified form of the ratio:


Measured length of scale on map ::: Length written on scale


If the scale given as a ratio. The scale factor is:


(((​Length written on scale))) ÷\div÷ (((Measured length of scale on map)))​


This is what you multiply the distances you measure on the map by to find the corresponding real world distance.



Scale drawings

Drawings can come equipped with a scale too, and all of the above holds true for drawings the same way it does for maps, including the procedure described for computing real distances between points - just replace the word "map" with drawing.


You might be asked to compute the scale factor of a drawing, to compute the true size of an object from a drawing with a given scale, or you could be asked to produce scale drawings given a scale factor and measurements.


Example 2

The following sketch of a house comes equipped with a scale. How tall is the house in metres? Suppose you measure the length of the scale to be 2cm2cm2cm. What is the scale factor of the drawing?

Maths; Angles and geometry; KS4 Year 10; Maps and scale drawings


The house is five blocks tall, and each block length corresponds to a real distance of 130cm130cm130cm, so the real height of the house is:


130cm×5=650cm=6.5m\begin{aligned}130cm \times 5 &= 650cm \\&= 6.5m\end{aligned}130cm×5​=650cm=6.5m​​​

​

If you measure the length of the scale to be 2cm2cm2cm, then the scale factor is given by (((length written on scale)))​ ÷\div÷​ (((​measured length of scale)))​, which is:


​130cm2cm=65\dfrac{130cm}{2cm} = 652cm130cm​=65​​

And as a ratio, the scale is 1:651:651:65.


Therefore, the house is 6.5m‾\underline{6.5m}6.5m​ tall, and the scale factor of the drawing is 65‾\underline{65}65​.



Read more

Learn with Basics

Learn the basics with theory units and practise what you learned with exercise sets!
Length:
Scale factor problems

Scale factor problems

Maps and scale drawings

Maps and scale drawings

Jump Ahead

Score 80% to jump directly to the final unit.

This is the current lesson and goal (target) of the path

Maps and scale drawings

Maps and scale drawings

Final Test

Test reviewing all units to claim a reward planet.

Create an account to complete the exercises

FAQs - Frequently Asked Questions

Do maps come with a scale?

A map must have a scale.

Why is map scale important?

You can measure the distance between two points on the map with a ruler, then use the scale to work out what the distance between the corresponding two points in the real world is.

What are the scales of a map?

You can use the scale to compute the true dimensions of the map.
