Coordinates allow you to talk about location on a coordinate grid with precision. In $2\text{D},$ $x$ and $y$ coordinates are conventionally used and together are denoted as $(x,y)$.
In $2\text{D},$ the coordinate grid (also known as the Cartesian grid) consists of an $x$-axis going horizontally and a $y$-axis going vertically:
The "origin" is the centre of the coordinate grid. When reading and plotting coordinates, start from the origin.
1. | To describe a point on the coordinate grid, read along the $x$-direction first (left or right) and find the number the point is in-line with. This number is the $x$-coordinate. |
2. | Then read along the $y$-direction (up or down). The number that the point is in-line with is the $y$-coordinate. |
3. | The coordinates are then written in the form $(x,y)$ where $x$ is the $x$-coordinate, and $y$ is the $y$-coordinate. |
If you have the point $(5,8)$ on the coordinate grid, it would be in-line with the $5$ on the $x$-axis and in-line with the $8$ on the $y$-axis, as shown below:
Note: Coordinates must be given with the $x$-coordinate first and the $y$-coordinate second. If you reverse these numbers, you end up with a different point! For example, if you look at $(8,5)$, you actually have the point depicted below:
Note: The origin has coordinates $(0,0)$.
1. | To plot a point on the coordinate grid, read the coordinates, which are in the form $(x,y)$. Read along the $x$-direction first (left or right) by the number given by $x$. If $x$ is positive, you go to the right of the origin, and if it is negative, you go left. |
2. | Then go along the $y$-direction (up or down) by the number given by $y$. If $y$ is positive, go up, and if it is negative, go down. |
3. | Mark the point on your coordinate grid. It is common to use a dot or a cross. |
Coordinates allow you to talk about location on a coordinate grid with precision. In $2\text{D},$ $x$ and $y$ coordinates are conventionally used and together are denoted as $(x,y)$.
In $2\text{D},$ the coordinate grid (also known as the Cartesian grid) consists of an $x$-axis going horizontally and a $y$-axis going vertically:
The "origin" is the centre of the coordinate grid. When reading and plotting coordinates, start from the origin.
1. | To describe a point on the coordinate grid, read along the $x$-direction first (left or right) and find the number the point is in-line with. This number is the $x$-coordinate. |
2. | Then read along the $y$-direction (up or down). The number that the point is in-line with is the $y$-coordinate. |
3. | The coordinates are then written in the form $(x,y)$ where $x$ is the $x$-coordinate, and $y$ is the $y$-coordinate. |
If you have the point $(5,8)$ on the coordinate grid, it would be in-line with the $5$ on the $x$-axis and in-line with the $8$ on the $y$-axis, as shown below:
Note: Coordinates must be given with the $x$-coordinate first and the $y$-coordinate second. If you reverse these numbers, you end up with a different point! For example, if you look at $(8,5)$, you actually have the point depicted below:
Note: The origin has coordinates $(0,0)$.
1. | To plot a point on the coordinate grid, read the coordinates, which are in the form $(x,y)$. Read along the $x$-direction first (left or right) by the number given by $x$. If $x$ is positive, you go to the right of the origin, and if it is negative, you go left. |
2. | Then go along the $y$-direction (up or down) by the number given by $y$. If $y$ is positive, go up, and if it is negative, go down. |
3. | Mark the point on your coordinate grid. It is common to use a dot or a cross. |
FAQs
Question: What is a Cartesian grid?
Answer: The Cartesian grid is the same thing as the coordinate grid.
Question: How do you find x and y coordinates?
Answer: Starting at the origin, go horizontally x places, given by the x-coordinate, then go y places vertically, given by the y-coordinate.
Question: Which comes first, x or y?
Answer: When denoting coordinates, the x-coordinate comes before the y-coordinate: (x,y)
